DALI+ provides DALI lighting control plus wireless and IP-based networking

“DALI+ extends choice, flexibility and creative freedom for lighting designers and specifiers by supporting the development of wired, wireless and IP-based systems, using DALI throughout.”

Technical Guide DALI+ Systems (September 2021)
Blog DALI+ provides DALI lighting control over IP and wireless networks (October 2021)
Press release DALI+ delivers DALI lighting control with wireless and IP-based networking (May 2021)
Specifications See below
Webinar DALI and Connectivity: Choice and flexibility with DALI+ and Wireless Gateways (July 2021)

DALI+ denotes DALI over wireless and IP-based networks

DALI+ devices communicate using existing DALI commands, but these are carried over a wireless and/or IP-based medium rather than the dedicated pair of wires used by DALI-2 and D4i.

DALI+ builds on the proven and sophisticated DALI lighting-control features in wired (DALI-2 and D4i) options, and offers access to the same rich set of data from control gear, luminaires and sensors.

>> Frequently-asked Questions

SPECIFICATIONS

DALI+ is supported by DiiA Specification "Part 104 Changes and Additions" which provides updates to the published Part 104 of the international IEC 62386 standard.

The first version of this new specification supports IP-based protocols such as Thread, Ethernet and Wi-Fi.

NOTE: “Part 104 Changes and Additions” will be further updated before certification starts.

Part 104 Changes & Additions Download from the DALI Alliance website
IEC 62386:104 Purchase from the IEC webstore

TESTING

An nRF52840 USB dongle from Nordic Semiconductors is required for DALI+ testing, in addition to the ProbitLab2 and other test equipment (see our Testing page). Further details will be given in the next release of the Product Submission Guide.


BRIDGES

The new Part 104 Changes & Additions specification supports bridges, which allow a DALI+ wireless network to access DALI wired subnets or luminaires.




CERTIFICATION

The first certification program for interoperable DALI+ devices will utilize Thread's low-power, IP-based, wireless-mesh networking protocol.

Tests are in development to enable DALI+ with Thread certification.

NOTE: “Part 104 Changes and Additions” will be further updated before certification starts.

View the joint Thread-DALI Alliance press release (May 2021)


Technical Guide




LINKS

>> Wireless to DALI Gateways

>> More about DALI over IP solutions

>> More about DALI and wireless





FAQs on DALI+

What’s the difference between DALI+ and wireless gateways?

View answer

Wireless to DALI gateways translate between the wireless protocol on one side and the wired DALI devices on the other side. Wireless devices (including the gateway) communicate using the wireless ecosystem protocol. With DALI+, there is no translation, and DALI commands are used throughout. In combination with a wireless carrier, DALI+ enables true wireless DALI.

Close

Why do we need another wireless protocol?

View answer

DALI+ is not a new protocol. DALI+ devices communicate using existing DALI commands, but these are carried over a wireless and/or IP-based medium. This provides choice and flexibility for anyone wishing to use DALI with different connectivity options.

Close

How does DALI+ handle security?

View answer

DALI+ uses security layers provided by the underlying protocol, with additional application-layer security features for DALI+ with Thread.

Close

Can you extend the number of devices beyond the 64+64 limit on a single subnet?

View answer

Yes. DALI+ includes a system address which multiplies the number of possible devices by 255. Where an IP-based carrier is used, such as Thread, this extension goes further, providing an almost unlimited addressing capability.

Close

How do you decide which protocols to support?

View answer

All our work on specifications and certification is guided by the priorities set by our members, as well as the availability of volunteers to carry out the necessary tasks; these include creating the specifications and test procedures, and evaluating the tests so that certification can begin. For DALI+, our members initially decided to work with the Thread Group to develop DALI+ with Thread certification. The Part 104 Changes & Additions specification itself supports IP-based carrier protocols such as Thread, Ethernet and Wi-Fi.

Close

Will DALI+ work over Ethernet, or WiFi, or Bluetooth mesh?

View answer

The first version of the new Part 104 Changes & Additions specification supports IP-based protocols such as Thread, Ethernet and Wi-Fi. Future versions of the specification may support other carriers. The first DALI+ certification program will support DALI+ with Thread.

Close

Will DALI+ certification be part of the DALI-2 (and D4i) certification program?

View answer

We are already working with Thread Group to develop DALI+ with Thread certification, which will be separate from DALI-2 certification. Different carriers will require their own DALI+ certification program.

Close

Is DALI+ compatible with D4i?

View answer

Yes. The new Part 104 Changes & Additions specification supports bridges, which allow wired DALI devices and luminaires (including D4i luminaires) to access the DALI+ network.

Close

Is DALI+ compatible with DALI-2?

View answer

Yes. The new Part 104 Changes & Additions specification supports bridges, which allow wired DALI-2 devices and luminaires to access the DALI+ network.

Close

Can DALI+ connect with a BMS?

View answer

Yes, it is possible for a DALI+ control device to incorporate an interface to a building management system (BMS).

Close

Why is certification important, and when will it start?

View answer

We have already started to develop the tests that are necessary to enable DALI+ with Thread certification. This process will take several months. Certification builds market confidence in the interoperability of products from different suppliers, and accelerates adoption.

Close

Is DALI data available with DALI+?

View answer

Yes, Parts 251-253, which cover luminaire, energy and diagnostics data, can all be implemented in DALI+ devices.

Close
